- FEATURES :
- It adopts the newest type high-power transmission mechanism to arrange the chain and drive the main driving shaft. The errors and noises of other gear wheel transmission can be avoided.
- Imported controlling system is adopted.
- It adopts photoelectrical controlling system to make Aluminum/Aluminum material to be automatically fed and waste side to be cut automatically to guarantee the Synchronous stability of over- length distance and multi stations.
- FLOW PROCESS :
Forming ->Filling -> Heating Sealing (up heating) -> Embossing -> Impression -> Cutting -> Finished product output
- APPLICATION :
The machine is suitable for industries of foodstuff, medicine, medical instruments,
hardware, electronics and etc for packing.
- TECHNICAL PARAMETER :
| PARAMETER | SPECIFICATION |
| Punch frequency | 10-33times/min |
| Production capacity | 1980plates/hour |
| Max. Forming area & Depth | 105×70 (standard depth ≦15mm), Max. Depth 25mm (As adjusted) |
| Standard Stroke range | 30-80 mm(can be designed as per user’s required) |
| Standard plate size | 80×57 mm (can be designed as per user’s required) |
| Air pressure | 0.4-0.6Mpa |
| Compressed air required | Air compressor ≥ 0.3m3/min |
| Total power supply | 380V/220V 50Hz 2.4 Kw |
| Main motor | 0.75 Kw |
| PTP Aluminum film | 0.02-0.035*110 (mm) |
| Mould cooling | Tap water or Recycling water |
| Overall Dimension (LxWxH) | 1840x590x1100 (mm) |
| Weight | Net 415 kg |
| Noise index | <75dBA |
5. SAFETY DEVICES :
| NO. | ITEM | FUNCTION |
| 1 | Emergency stop (Schneider) | Stop main machine in case of emergency situation |
