- FEATURES :
- Powder Tank : Dual layer with water cooling system.
- Oil Tank : Dual layer with heating function.
- Oil Spray : New Technology of pressure type oil spraying, oil evenly sprayed and nearly no remain oil in pipe.
- TECHNICAL PARAMETER :
| PARAMETER | SPECIFICATION |
| Tank Volume | 50L |
| Tank Material | Dual Layer SUS304 tank, inner layer SUS316L |
| Number of Side Stirrer | One shaft |
| Main Stirrer Motor | 11KW, 0-2840RPM |
| Side Stirrer Motor | 2.2KW, 2840RPM |
| Batch Production | 5-10KG |
| Outer Dimension | 1500*900*1500mm |
| Weight | 350KGS |
| Power Supply | AC380V or 220V, 3P, 50/60HZ |
- MAIN PART SPECIFICATION
| NO. | ITEM | SPECIFICATION |
| 1. | Tank Material | SUS304 |
| 2. | PLC | Mitsubishi |
| 3. | VFD | China |
| 4. | Touch Screen | China |
| 5. | Inner parts | SUS316L |
| 6. | Main Electric Elements | Schneider (France) |
- SAFETY DEVICES
| NO. | ITEM | FUNCTION |
| 1. | Emergency stop | Stop main machine in case of emergency situation |
