- FEATURES :
Adopt servo or steeping motor. Standard PLC touch screen, standard sensor
electronic control system control safety coefficient is high, easy to use, simple
maintenance. Have any label, no standard automatic correction and automatic
detection function.
2. TECHNICAL PARAMETER :
| Technical parameter | Specification |
| Labeling Speed | 20-70 bottles/min |
| Labeling Accuracy | ± 1 mm (depend on the evenness of the plane) |
| Printer to use air | 5 kg/cm2 |
| Label Size | H : 10-150 mm ; L : 20 – 200 mm |
| Cover Size | W : 30 – 300 mm ; L : 30 – 400 mm |
| Roll Size Inside | 76 mm ; outside : 350 mm |
| Voltage | AC 220V, 50/60 HZ 1 phase |
| Power consumption | 75 watt |
| Weight | 300 kg |
| Dimension (LxWxH) | 2120 ×860 × 1570 mm |
| Driving mode | Servo or stepping motor |
3. MAIN PART SPECIFICATIONS :
| NO. | ITEM | MERK/BRAND |
| 1. | Conveyor Motor + Gear Box | TCG (Taiwan) |
| 2. | PLC | Siemens (Germany) |
| 3. | Inverter | Danfoss (Denmark) |
| 4. | HMI | Siemens (Germany) |
| 5. | Electrical Part | Schneider (France) |
| 6. | Servo Labeling Motor | China |
| 7. | Optical | Omron (Japan) |
| 8. | Label stock electric eye | Omron (Japan) |
4. SENSOR :
| NO. | ITEM | FUNCTION |
| 1. | Label detection sensor (Leuze Germany) | Precise label detection |
| 2. | Label Stock Sensor (Omron) | Detect label stock |
| 3. | Bottle sensor (Omron – Japan) | To detect bottle in conveyor |
5. SAFETY DEVICES :
| NO. | ITEM | FUNCTION |
| 4. | Emergency stop | Stops main machine in case of emergency situation |
